20RA

Developed for smaller equipment where space is at a premium, the model #20RA alignment system comes with every component necessary to align machinery with shaft sizes from 3/4" to 4" in diameter. The alignment frames are precision milled from 6061-T6 aircraft grade aluminum.

#20RA Kit Contents

• Two (2) alignment frames, each with one (1) 1/2 inch diameter mounting hole for tubing.
• 20" of #41 roller chain (attached to frame).
• 2 dial indicator assemblies with swivel joints and mounting rods.
• 2 each of 1/2" diameter tubing in 5", 7" and 9" lengths.
• Allen key, 3/16".
• Instruction manual.
• FastMath(tm) worksheets.
• Durable carrying case with handle.
• Now includes the Alignment Manager Software for Windows
